The Veil Nebula

Summer is ebbing. The great seasonal triangle of Vega, Deneb and Altair opens the night higher and higher in the sky and soon will at zenith by 10pm. That means that I soon won't be able to image targets in Cygnus, since they are slowly slipping behind the house and out of my -- way too limited -- field of view.

So, before that happens, I figured it was time to capture the glories of The Veil Nebula. This sweeping collection of filamentary wisps of nebulosity is all that remains of a massive star that went supernova between 7,000 and 10,000 years ago. The Veil covers a considerable amount of sky and its constituent components include NGC 6992, NGC 6995 and NGC 6960.

The Veil is particularly strong in hydrogen and oxygen, which makes it an excellent target for narrowband imaging. The following images were taken using the Ha and OIII filters, combined to create bicolor images with a HOO profile.

Spread out over so large an area, the Veil is impossible to fit into one image, even with the Evostar 72ED's quite wide FOV. Thus, I imaged the nebula in two parts: the Eastern Veil, including NGC 6992 and then the Western Veil, including NGC 6960. Late August weather hasn't been kind to sky watchers here in New York, but I managed to get four nights over the past two weeks, spending two nights on each image.

The two resulting images were then combined in Pixinsight to create a single image that captures most, though not all, of the Veil Nebula complex.

The Western Veil, including NGC 6960:

Captured on two nights in mid August. The below image is composed of 88, 180-second sub-exposures - 44 shot through the Ha filter and 44 through the OIII filter. The image nicely captures Pickering's Triangle, the expanse of twisting, gossamer filaments to the right edge of the image.

The Eastern Veil, including NGC 6992

This portion of the Veil is a favorite target for imagers. I have shot it before with both the DSLR and the SSP -- and I think I managed to capture parts of it years ago with the Meade DSI. But the ASI1600 does it particular justice. This image was captured over two nights and is composed of 78, 180-second sub-exposures, including 42 shot through the Ha filter and 36 through the OIII filter.

The Veil Nebula Complete (well, mostly)

With both the Western and Eastern sections captured, I used dnaLinearFit, Star Alignment and GradientMergeMosaic in Pixinsight to combine the two images and produce the below mosaic, which captures the majority of the nebula complex. Some nebulosity was clipped at the top and bottom of the image, which leaves me something to target next year.

I am very pleased with both panels and the final combined mosaic. It is a nice way to see summer come to its end.

Summer 2019 - Major Upgrades

New Mount, New Camera, New Images

In December 2018, my old Meade LXD75 mount suffered a total R.A. motor failure. After a decade of far better service than I should have expected -- the LXD line was not Meade's best or most accurate equatorial mount -- it was time to move on. After considerable research, I settled on the Sky Watcher EQ6-R Pro, which I ordered through Highpoint Scientific.

The new mount quickly proved far more capable and reliable than the LXD, which was not unexpected. Since I had upgraded the mount, I decided it was time to do likewise with the camera. I had been using a Gary Honis-full spectrum modified Canon EOS T2i since 2014 and had reached its limits. After more research, I settled on a ZWO ASI1600MM Pro. This was a major change from the one-shot-color (OSC) imaging that I had been doing for years. But a switch to Mono (a monochrome chip), seemed like the next step in my imaging development. So I took the plunge. Since I still wanted to capture color images, and because I was interested in using Narrowband filters, I selected the ASI1600MM Pro kit with an electronic filter wheel and 31mm L, R, G, B, Ha, OIII and SII filters.

Naturally, once the new camera arrived in early April, six weeks of clouds and rain followed. During that time, I decide that, having spent money on a new mount and camera, I might as well purchase a new scope to go with them. I had grown a little tired of constantly collimating my 6" Orion Newtonian Astrograph, so I purchased a Sky Watcher Evostar 72 ED, a 72mm doublet refractor, which promised a very wide field of view. With the added .8 field flattener/reducer that already wide field was widened even more.

Having indulged myself with a new mount, camera and telescope, I decided to spend even more money. I purchased Pixinsight, the leading astro-imaging processing software and took a subscription to Photoshop. At this point, why not?

Between the software and camera, there was an inevitable learning curve, but by June, I was amazing myself with images that far better matched what I had long hoped to achieve in astro-imaging. The ASI1600 has proven extremely versatile and sensitive, allowing me to capture objects that were just too faint for the DSLR (and SSP before it). I had long avoiding Mono imaging because I figured it would be too difficult. However, the reality is that with contemporary electronic filter wheels and software (I use Astrophotography Tool - APT), the process is relatively simple. There are a few more steps, but not many, and the results amply justify the extra effort.

So, here are some of the highlights of the last eight weeks, through mid August.

NGC 884 & 869 - The Double Cluster

A preview of fall's coming attractions. Less than 20 minutes of exposure through RGB.

M8, M20 and NGC 6559

I am particularly pleased with this image, which captures M20, the  Trifid Nebula (upper middle/right), M8, the Lagoon Nebula (lower right) and NGC 6559 (lower left), in one image. More so, because this is actually two images that Pixinsight combined into a mosaic. The 72ED's FOV is generous enough the capture M8 and M20 in one shot, but not all three objects.

M11 - The Wild Dust Cluster

Under 20 minutes of RGB exposure time, but enough to bring out the dense starfield and wispy dark nebula in the region around the cluster.

M27 - The Dumbbell Nebula

This image is one of my first Narrowband images, a combination of Ha and OIII subs.

M31 - The Andromeda Galaxy

Another preview of fall. This image is composed of just over 30 minutes of 60-second RGB subs, which shows the considerable power of the ASI1600.

NGC7635, M52 & Friends

This image truly brought home the power of mono imaging and the sensitivity of the ASI1600. I have been imaging the beautiful cluster M52 (top/center) and NGC 7635, the Bubble Nebula (mid center/left), and NGC 7538 (lower center/right) for years, completely unaware of the other objects - Sh2-157 (the Lobster Claw - lower left) and extended nebulosity between NGC 7635 and NGC 7538 (mid to lower right). The DSLR was simply not sensitive enough to capture them.

NGC 7000 and NGC 5070

This mosaic of two images capturing the North American Nebula (NGC 7000) and the Pelican Nebula (NGC 5070) puts just about every astro-image I'd taken before to shame. This image is under an hour of HaRBG integration, with subs of just 60 seconds.

NGC7023 - Iris Nebula

Notoriously difficult to bring out the dust clouds surrounding the Iris, but at just 5 hours of RGB integration, the ASI1600 does a good job.

NGC7293 - The Double Helix Nebula

Just under eight hours of Ha and OIII, with subs ranging from 600 seconds to 180 seconds.

NGC7822

A region of emission nebula and star clusters in Cepheus.

Sh2-101 - The Tulip Nebula

About an hour RGB integration in Cygnus.

Sh2-157 - The Lobster Claw

Spotted whilst imaging the Bubble Nebula (NGC 7635 - upper center/right), the Lobster Claw demanded its own image. About two hours of integration in RGB using 300-second subs.
